Blue Sea Systems E-Series Dual Circuit Plus Red Battery Switch (No AFD)

Description

Features:
• Simultaneously switches two isolated battery banks or combines battery banks to all loads
• Make-before-break contact design allows switching without power interruption
• Ignition protected„safe for installation on gasoline powered trucks and buggies
• Case design allows surface or rear panel mounting

Specifications:
• Switch Type: Dual Circuit Plus
• Color: Red
• Switch Positions: 3
• Battery Combine: Yes
• Alternator Field Disconnect: No
• Maximum Voltage: 32V DC
• Terminal Stud Torque: 140 in-lb (15.82 Nm)
• Continuous Rating: 350A
• Intermittent Rating: 525A (5 min)
• Cranking Rating 10 sec: 1000A
• Cranking Rating 1 min: 750A
• Battery Inputs: 2
• Cable Clearance For 4/0 AWG Cables: 1.12in (28.45 mm)
• Cable Size to Meet Ratings: 4/0 AWG (120mm*)
• Mounting Holes: Accept 1/4″ (M6) Screw
• Terminal Stud Size: 3/8″ – 16 (M10)
• Weight: 1.30lb (0.59 kg)

Features:
• Simultaneously switches two isolated battery banks or combines battery banks to all loads
• Make-before-break contact design allows switching without power interruption
• Ignition protected„safe for installation on gasoline powered trucks and buggies
• Case design allows surface or rear panel mounting

Specifications:
• Switch Type: Dual Circuit Plus
• Color: Red
• Switch Positions: 3
• Battery Combine: Yes
• Alternator Field Disconnect: No
• Maximum Voltage: 32V DC
• Terminal Stud Torque: 140 in-lb (15.82 Nm)
• Continuous Rating: 350A
• Intermittent Rating: 525A (5 min)
• Cranking Rating 10 sec: 1000A
• Cranking Rating 1 min: 750A
• Battery Inputs: 2
• Cable Clearance For 4/0 AWG Cables: 1.12in (28.45 mm)
• Cable Size to Meet Ratings: 4/0 AWG (120mm*)
• Mounting Holes: Accept 1/4″ (M6) Screw
• Terminal Stud Size: 3/8″ – 16 (M10)
• Weight: 1.30lb (0.59 kg)
