Blue Sea Systems HD-Series Gray Dual-Battery Switch with Alternator Field Disconnect

Description

Features:
• Switches isolated battery banks to all loads or combines battery banks to all loads
• Includes AFD (Alternator Field Disconnect)
• Make-before-break contact design allows switching between battery banks without power interruption
• Ignition protected„safe for installation on gasoline powered trucks and buggies
• Case design allows surface or rear panel mounting

Specifications:
• Switch Type: Selector 4 Position
• Color: Gray
• Switch Positions: 4
• Battery Combine: Yes
• Alternator Field Disconnect: Yes
• Maximum Voltage: 32V DC
• Terminal Stud Torque: 220 in-lb (24.86 Nm)
• Continuous Rating: 500A
• Intermittent Rating: 700A (5 min)
• Cranking Rating 10 sec: 2750A
• Cranking Rating 1 min: 1150A
• Battery Inputs: 2
• Cable Clearance For 4/0 AWG Cables: 1.12in (28.45 mm)
• Cable Size to Meet Ratings: 4/0 AWG (120mm*)
• Mounting Holes: Accept 1/4″ (M6) Screw
• Terminal Stud Size: 3/8″ – 16 (M10)
• Weight: 1.25lb (0.57 kg)

Features:
• Switches isolated battery banks to all loads or combines battery banks to all loads
• Includes AFD (Alternator Field Disconnect)
• Make-before-break contact design allows switching between battery banks without power interruption
• Ignition protected„safe for installation on gasoline powered trucks and buggies
• Case design allows surface or rear panel mounting

Specifications:
• Switch Type: Selector 4 Position
• Color: Gray
• Switch Positions: 4
• Battery Combine: Yes
• Alternator Field Disconnect: Yes
• Maximum Voltage: 32V DC
• Terminal Stud Torque: 220 in-lb (24.86 Nm)
• Continuous Rating: 500A
• Intermittent Rating: 700A (5 min)
• Cranking Rating 10 sec: 2750A
• Cranking Rating 1 min: 1150A
• Battery Inputs: 2
• Cable Clearance For 4/0 AWG Cables: 1.12in (28.45 mm)
• Cable Size to Meet Ratings: 4/0 AWG (120mm*)
• Mounting Holes: Accept 1/4″ (M6) Screw
• Terminal Stud Size: 3/8″ – 16 (M10)
• Weight: 1.25lb (0.57 kg)
