Description
FK’s CM series heim joint rod end bearings. A 2-piece design that is chrome plated for light duty applications such as shifter linkages, steering shaft supports and throttle linkages. Available with left handed threads.
Features
- 2 Piece, Low Carbon Steel Body
- Hard Chrome Plated
- 52100 Steel Ball
- For light duty applications
| Part Number | Bore | Thread Pitch | Direction |
| FKB-CM3 | 3/16″ bore | 10-32 thread | Right Hand |
| FKB-CM4 | 1/4″ bore | 1/4″-28 thread | Right Hand |
| FKB-CM5 | 5/16″ bore | 5/16″-24 thread | Right Hand |
| FKB-CM6 | 3/8″ bore | 3/8″-24 thread | Right Hand |
| FKB-CM7 | 7/16″ bore | 7/16″-20 thread | Right Hand |
| FKB-CM8 | 1/2″ bore | 1/2″-20 shank | Right Hand |
| FKB-CM10 | 5/8″ bore | 5/8″-18 thread | Right Hand |
| FKB-CM12 | 3/4″ bore | 3/4″-16 thread | Right Hand |
| FKB-CM12757 | 0.757 bore | 3/4″-16 thread | Right Hand |
FK’s CM series heim joint rod end bearings. A 2-piece design that is chrome plated for light duty applications such as shifter linkages, steering shaft supports and throttle linkages. Available with left handed threads.
Features
- 2 Piece, Low Carbon Steel Body
- Hard Chrome Plated
- 52100 Steel Ball
- For light duty applications
| Part Number | Bore | Thread Pitch | Direction |
| FKB-CM3 | 3/16″ bore | 10-32 thread | Right Hand |
| FKB-CM4 | 1/4″ bore | 1/4″-28 thread | Right Hand |
| FKB-CM5 | 5/16″ bore | 5/16″-24 thread | Right Hand |
| FKB-CM6 | 3/8″ bore | 3/8″-24 thread | Right Hand |
| FKB-CM7 | 7/16″ bore | 7/16″-20 thread | Right Hand |
| FKB-CM8 | 1/2″ bore | 1/2″-20 shank | Right Hand |
| FKB-CM10 | 5/8″ bore | 5/8″-18 thread | Right Hand |
| FKB-CM12 | 3/4″ bore | 3/4″-16 thread | Right Hand |
| FKB-CM12757 | 0.757 bore | 3/4″-16 thread | Right Hand |
